Bently Nevada 330930-060-01-CN | 3300 NSv Extension Cable

Overview

The Bently Nevada 330930-060-01-CN is a 6-meter (19.7 feet) extension cable designed for use with the 3300 NSv proximity probe. Manufactured in the USA, this high-quality extension cable features stainless steel armor with an FEP jacket, offering increased durability in harsh industrial environments. It is compatible with Bently Nevada’s 3300 NSv probe and ensures optimal performance in demanding process compressor applications.

Key Features:

• Material: 75 Ω coaxial, fluoroethylene propylene (FEP) insulated.
• Connector Type: Gold-plated brass with ClickLoc connectors, preventing disconnections and ensuring secure electrical connections.
• Cable Armor: Stainless steel flexible armor with an optional FEP outer jacket for added protection.
• Temperature Range: Operates in extreme conditions with a temperature range of -51°C to +177°C (-60°F to +351°F).
• Tensile Strength: 220 N (50 lb) rated at multiple connection points, ensuring reliable cable attachment.
• Extension Cable Capacitance: 69.9 pF/m (21.3 pF/ft) typical.

Technical Specifications:

• Brand: Bently Nevada
• Model: 330930-060-01-CN
• Cable Length: 6.0 meters (19.7 feet)
• Material: Coaxial 75 Ω, FEP insulated
• Operating Temperature: -51°C to +177°C (-60°F to +351°F)
• Resistance:
  • Center Conductor: 0.220 Ω/m (0.067 Ω/ft)
  • Shield: 0.066 Ω/m (0.020 Ω/ft)
• Capacitance: 69.9 pF/m (21.3 pF/ft)
• Armor: Stainless steel flexible, optional FEP outer jacket
• Connector: Gold-plated brass ClickLoc connectors
• Pull Strength: 220 N (50 lb) at multiple connection points

Frequently Asked Questions (FAQ):

1. What is the length of the 330930-060-01-CN extension cable?
   • The cable is 6.0 meters (19.7 feet) long.
2. What type of material is used for the cable insulation?
   • The cable uses 75 Ω coaxial, fluoroethylene propylene (FEP) insulation.
3. What temperature range does this cable support?
   • The cable operates in a temperature range from -51°C to +177°C (-60°F to +351°F).
4. Is the cable resistant to harsh chemicals?
   • Yes, the NSv probe and extension cable have increased chemical resistance, suitable for process compressor applications.
5. What is the tensile strength of the cable?
   • The extension cable has a tensile strength of 220 N (50 lb) at multiple connection points.

For more detailed information: 3300 XL NSv Proximity Transducer System Datasheet
