Bently Nevada 9200-06-02-10-00 Two-wire Transducer

Overview

The Bently Nevada 9200-06-02-10-00 is a highly accurate Two-Wire Velocity Seismoprobe Transducer, designed to measure vibration velocity in industrial applications. Manufactured in the U.S.A., it is built with a durable anodized aluminum casing and offers a wide frequency response from 10 Hz to 1000 Hz, making it ideal for monitoring machinery and equipment vibrations.

Features:

• High Sensitivity: 20 mV/mm/s (500 mV/in/s) at ±5% sensitivity.
• Compact Design: 102 mm height and 41 mm diameter, with a side-mount connector option.
• Durable Construction: Made from anodized aluminum A204 and neoprene gasket for long-lasting performance.
• Wide Frequency Response: 4.5 to 1000 Hz (270 to 60,000 CPM) with ±3 dB typical.
• Shock Resistance: Withstands 50 g peak acceleration along non-sensitive axis.
• Polarity of Output Signal: Pin A goes positive when transducer velocity is towards the connector.
• Environmental Limits: Operating temperature range from -29°C to +121°C (-20°F to +250°F).

Technical Specifications:

• Brand: Bently Nevada
• Model: 9200-06-02-10-00
• Transducer Type: Two-Wire Velocity Seismoprobe
• Frequency Response: 4.5 to 1000 Hz (+0, -3 dB typical)
• Sensitivity: 20 mV/mm/s (500 mV/in/s), ±5%
• Mounting Options: Side mount with M10X1 stud; Circular base option.
• Shock Resistance: 50 g peak, max acceleration along non-sensitive axis.
• Environmental Temperature Limits: -29°C to +121°C
• Weight: 300 grams (10.5 oz) typical.
• Coil Resistance: 1.25 kΩ ±5%
• Inductance: 125 mH (typical)
• Connector Options: Side mount, cadmium-plated aluminum.
• Terminal Block Material: Polyphenylene sulfide with nickel-plated copper contacts.

FAQ:

1. What is the maximum lead wire length for this transducer?
   • The maximum lead wire length is 305 meters (1000 feet) between the Seismoprobe and the monitor.
2. What is the mounting torque for the transducer?
   • The recommended mounting torque for the M10X1 base option is 5.6 N•m (50 in•lb).
3. What environmental conditions can the Seismoprobe withstand?
   • It operates within a temperature range of -29°C to +121°C and is built to endure industrial environments.

Check official datasheet for more detailed information:9200 and 74712 Seismoprobe Velocity Transducers Datasheet
