Bently Nevada | 990-05-50-01-00 Two-wire Vibration Transmitter

Technical Specifications for 990-05-50-01-00 Vibration Transmitter

• Brand: Bently Nevada
• Model: 990-05-50-01-00
• Product Type: Vibration Transmitter
• Full-Scale Option: 05 0-5 mils pp (0-125 μm pp)
• System Length Option: 50 5.0 meters (16.4 feet)
• Mounting Option: 01 35 mm DIN rail clips
• Agency Approval: 00 Not required
• Probe Case Material: AISI 303 or 304 Stainless Steel (SST)
• Probe Cable: 75Ω coaxial, fluoroethylene propylene (FEP) insulated
• Cable Armor: Flexible AISI 302 SST (optional) with optional FEP outer jacket
• Transducer Tip Material: Polyphenylene Sulfide (PPS)
• Transducer Case Material: AISI 303 or 304 Stainless Steel (SST)
• Weight: 0.82 Kg (Transmitter: 0.43 kg)
• Tensile Strength: 222 N (50 lbf) probe case to probe lead, maximum
• Operating Temperature: -35°C to +85°C (-31°F to +185°F)
• Storage Temperature: -52°C to +100°C (-62°F to +212°F)

Application

The Bently Nevada 990 Vibration Transmitter is ideal for industries that require real-time vibration measurement, such as:

• Power Generation
• Oil and Gas
• Manufacturing
• Automotive
• Aerospace

It is often used in critical machinery monitoring and predictive maintenance systems to detect early signs of mechanical failure, reducing downtime and preventing costly repairs.

Frequently Asked Questions (FAQ)

1. What does the “990” model number mean?
The “990” series from Bently Nevada is dedicated to high-precision vibration measurement, commonly used in industrial applications for machinery health monitoring.

2. Can I customize the length of the probe cable?
Yes, the system length option comes in various lengths, with 5.0 meters (16.4 feet) being standard. Custom cable lengths are available upon request.

3. What materials are used in the construction of the probe case?
The probe case is constructed from high-quality AISI 303 or 304 stainless steel, ensuring durability and resistance to harsh environments.

4. Is the 990 Vibration Transmitter suitable for extreme temperatures?
Yes, the 990 series operates efficiently in temperatures ranging from -35°C to +85°C, and it can withstand storage conditions between -52°C and +100°C.

For more detailed information:990 Vibration Transmitter Datasheet
