Bently Nevada | 991 Thrust Transmitter 991-06-50-01-01

Overview:

The Bently Nevada 991-06-50-01-01 Thrust Transmitter is designed for highly accurate thrust and displacement monitoring. Ideal for industrial applications, it offers precise measurement, durable construction, and easy integration into control systems.

Technical Specifications

• Manufacturer: Bently Nevada
• Product Model: 991-06-50-01-01
• Product Type: Thrust Transmitter
• Made in: U.S.A
• Model Suffix Explanation:
  • 991: Product series for thrust and displacement monitoring
  • 06: Indicates a specific configuration or customization option
  • 50: Model identifier for thrust measurement
  • 01-01: Further customization or design version
• Full-Scale Range Option:
  • 0.6 mm to -0.6 mm displacement range
  • Highly precise measurement accuracy within ±1.5% over the full-scale range (typical)
• Input Requirements:
  • Accepts one non-contacting 3300 NSv proximity probe
  • Requires a voltage input of +12 to +35 Vdc at the transmitter terminal
• Output:
  • 4 to 20 mA output signal, perfect for integration in control systems
  • Loop resistance maximum: 1,000 Ω at 35 Vdc
  • Current Limiting: 23 mA typical
• Transducer Materials:
  • Transducer Tip: Polyphenylene sulfide (PPS)
  • Transducer Case: AISI 303 or 304 Stainless Steel (SST)
  • Probe Cable: 75Ω coaxial, fluoroethylene propylene (FEP) insulated
  • Cable Armor (optional): Flexible AISI 302 SST with optional FEP outer jacket
  • Tensile Strength: 222 N (50 lbf) maximum for probe case to probe lead
• Mounting Options:
  • Includes 35 mm DIN-rail clips for easy installation
• Approval Options:
  • CSA Division 2 approval for use in hazardous locations
• System Length:
  • 5 meters (16.4 feet) option for system integration flexibility
• Weight:
  • 0.43 kg (0.9 lbm)

FAQ

Q1: What is the full-scale range of the Bently Nevada 991-06-50-01-01 Thrust Transmitter?
A1: The full-scale range is customizable, with a typical configuration offering a range of 0.6 mm to -0.6 mm.

Q2: What power input does the thrust transmitter require?
A2: The transmitter requires a DC voltage input of +12 to +35 Vdc.

Q3: How does the transmitter connect to control systems?
A3: It features a 4 to 20 mA output signal, which is standard for control systems in industrial automation.

Q4: Is the transmitter suitable for use in hazardous environments?
A4: Yes, the transmitter has CSA Division 2 approval, making it ideal for use in hazardous locations.

For more detailed information:991 Thrust Transmitter Datasheet
