Bently Nevada | ETR Extension Cable 330190-085-01-CN

Overview:

The Bently Nevada 330190-085-01-CN 3300 XL 8mm Proximity Transducer System is a precision measurement tool for monitoring rotating machinery and detecting displacement, vibration, and position changes. It features advanced technology with a rugged design to ensure high accuracy in industrial environments. Made in the USA, this system can be ordered with a Certificate of Origin (COO).

Technical Specifications:

• Brand: Bently Nevada
• Model: 3300 XL 8mm Proximity Transducer System
• Part No.: 330190-085-01-CN
• Cable Length: 8.5 meters (27.9 feet)
• Cable Type: Armored cable (Option 01)
• Voltage: Requires -17.5 Vdc to -26 Vdc for non-incendive circuit connection; -23 Vdc to -26 Vdc with barriers.
• Operating Altitude: Maximum 2000 meters
• Power Consumption: 12 mA maximum
• Output Resistance: 50 Ω
• Probe Tip Material: Polyphenylene sulfide (PPS)
• Sensitivity: Less than 2 mV change in output voltage per volt change in input voltage.
• Temperature:
  • Standard Probe: -52°C to +177°C (-62°F to +350°F)
  • Extended Probe: Up to -52°C to +218°C (-62°F to +425°F) for probe tip, -51°C to +260°C (-60°F to +500°F) for probe cable and connector.
• Target Material: AISI 4140 steel (system calibration applies to this target).

FAQ:

1. What is the cable length option?
   The system comes with an 8.5-meter (27.9 feet) armored cable.
2. What industries use the 3300 XL Proximity Transducer?
   It is commonly used in power generation, petrochemical, and manufacturing industries.
3. What is the operating temperature range of the probe?
   The probe can operate within a standard temperature range of -52°C to +177°C, with an extended range for higher temperatures.

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
