Bently Nevada FluidLoc Cable | 330130-035-12-05

Overview

The Bently Nevada 330130-035-12-05 3300 XL Standard Extension Cable is a high-performance accessory engineered to enhance the reliability and precision of proximity measurement systems. Designed for use with 3300 XL 8 mm Proximitor Sensors, this extension cable features advanced capabilities, including patented FluidLoc technology for superior oil resistance, ensuring minimal leakage and extended operational durability.

Key Features

• Brand & Model: Bently Nevada 330130-035-12-05
• Cable Length: 3.5 meters (11.5 feet)
• Connector Option: FluidLoc cable with a connector protector for enhanced durability.
• Agency Approvals: Certified with CSA, ATEX, and IECEx standards for safe use in industrial environments.
• Enhanced Designs: TipLoc molding for robust probe tip bonding and CableLoc for 330 N pull strength.
• Operational Temperature Range: Designed to perform optimally between +18˚C and +27˚C.

Technical Specifications

Extension Cable Properties

• DC Resistance (Center to Center):
  • 3.5 m: 0.77 ± 0.12 Ω
• Resistance (Outer Conductor to Outer Conductor):
  • 3.5 m: 0.23 ± 0.05 Ω
• Capacitance: 69.9 pF/m (21.3 pF/ft), typical

Proximitor Sensor System Requirements

• Power Supply:
  • -17.5 Vdc to -26 Vdc; maximum 12 mA consumption.
• Field Wiring Compatibility:
  • 16–24 AWG shielded triad cable recommended.
  • Maximum wiring length: 305 meters (1,000 feet).
• Linear Range: 2 mm (80 mils), starting at 0.25 mm (10 mils) from the target.

330130-035-12-05 Suffix Details

• 035: Specifies a 3.5-meter cable length.
• 12: Indicates the FluidLoc cable with connector protection.
• 05: Refers to agency approvals for CSA, ATEX, and IECEx.

FAQ

• Q: What is the purpose of FluidLoc technology?
  A: FluidLoc prevents oil and other liquids from migrating through the cable, reducing the risk of leakage and contamination in sensitive environments.
• Q: What is the pull strength of the CableLoc design?
  A: The CableLoc design provides a pull strength of 330 N (75 lbf) for secure attachment.

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
