Overview
Firstly, the Bently Nevada 330101-00-30-50-02-05 3300 XL 8 mm Probe is a revolutionary solution for industrial monitoring. Secondly, compared to previous models, it features significant improvements. For instance, the patented TipLoc molding method provides a stronger bond between the probe tip and the body. Additionally, the CableLoc design enhances the cable – probe connection. Moreover, the optional FluidLoc cable can effectively prevent liquid leakage, ensuring reliable performance in harsh environments.
Technical Specification
General Information
| Parameter | Details |
|---|---|
| Brand | Bently Nevada |
| Model | 3300 XL 8 mm Probe |
| Product No. Suffix Meaning | – ā00ā in ā330101-00-30-50-02-05ā means unthreaded length is 0.0 inches. – ā30ā indicates overall case length is 3.0 inches. – ā50ā represents total length is 5.0 meters (16.4 feet). – ā02ā stands for Miniature coaxial ClickLoc connector with standard cable. – ā05ā shows CSA, ATEX, IECEx Approvals. |
Performance and Physical Parameters
| Parameter | Details |
|---|---|
| Extension Cable Capacitance | Typically, it is 69.9 pF/m (21.3 pF/ft). |
| Field Wiring | It should be in the range of 0.2 to 1.5 mmĀ² (16 to 24 AWG), and a 3 – conductor shielded triad cable is recommended. |
| Linear Range | It is 2 mm (80 mils), starting from about 0.25 mm (10 mils) from the target. |
| Probe Tip Material | Polyphenylene sulfide (PPS). |
| Probe Case Material | It is AISI 303 or 304 stainless steel (SST). |
Contact Information
For any inquiries, please contact: [email protected]
For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
