Bently Nevada Proximity Transducer | 330880-28-30-037-01-02

Overview

The Bently Nevada 330880-28-30-037-01-02 PROXPAC XL Proximity Transducer is a robust monitoring solution designed for high-performance industrial applications. This system integrates a 3300 XL 8 mm proximity probe with advanced approvals for precise and reliable vibration and position monitoring in rotating machinery. Built with rugged materials and certified for IP66, it ensures reliable performance in harsh environments.

Features

• Wide Voltage Range: Operates between -17.5 Vdc to -26 Vdc for flexible power configurations.
• High Sensitivity: Less than 2 mV output change per input voltage change ensures accurate readings.
• Robust Materials: Constructed with AISI 304 stainless steel and glass-reinforced thermoplastic for durability.
• Superior Environmental Protection: IP66 housing ensures protection against dust and water.
• Flexible Mounting: Comes with a 3/4-14 NPT fitting and a 3/4-14 NPT to 1/2-14 NPT SST reducer for diverse installations.
• Wide Operating Range: Designed for temperatures from 0°C to +45°C (+32°F to +113°F).

Technical Specifications

• Brand/Model: Bently Nevada 330880-28-30-037-01-02
• Probe Input: 3300 XL 8 mm proximity probe, 1-metre cable.
• Output Resistance: 50 Ω
• Frequency Response: 0 to 10 kHz (+0, -3 dB).
• Material: Polyphenylene Sulfide (PPS) for probe tip, AISI 304 stainless steel for casing.
• Shaft Diameter: Recommended minimum of 76.2 mm (3.0 in).
• Target Size: Minimum 15.2 mm (0.6 in) diameter, flat target.
• Approvals: BASEEFA report number T07/0709 verifies IP66 rating.

FAQ

1. What is the minimum shaft diameter for this transducer?

• The recommended minimum shaft diameter is 76.2 mm (3.0 in).

2. Can this device be used in harsh environments?

• Yes, the IP66-rated housing ensures protection against dust and water ingress.

3. What is the cable length of the proximity probe?

• The probe comes with a standard 1-metre cable.

Check official datasheet for more detailed information: PROXPAC XL Proximity Transducer Assembly Datasheet
