Bently Nevada Reverse Mount Probes | 330907-05-30-10-12-CN

Overview

The Bently Nevada 3300 NSv Reverse Mount Probe (Model: 330907-05-30-10-12-CN) is a state-of-the-art sensor designed for use in process compressor applications where chemical resistance is crucial. Made in the USA, this advanced probe features superior side-view characteristics compared to earlier models, enhancing performance and reliability. Additionally, it is capable of withstanding extreme operating temperatures and high differential pressures, thanks to its robust construction including a stainless steel case and specialized sealing materials.

Technical Specifications

The technical specifications of the Bently Nevada 3300 NSv Reverse Mount Probe are outlined below:

• Brand: Bently Nevada
• Model: 3300 NSv Reverse Mount Probe
• Ordering Information:
  • Product No.: 330907-05-30-10-12-CN
  • Threads: M10X1
  • Total Length: 10 inches (1.0 meter)
  • Connector: Miniature coaxial ClickLoc with FluidLoc cable
  • Agency Approval: CN (Chinese Country Specific)
• Mechanical Properties:
  • Probe Tip Material: Polyphenylene sulfide (PPS)
  • Probe Case Material: AISI 304 stainless steel
  • Maximum Torque: 22.6 N•m (reverse mount probes)
• Electrical Characteristics:
  • Probe dc Resistance: 4.2 ± 0.5 ohms at 1.0 m
  • Field Wiring Range: 0.2 to 1.5 mm² (16 to 24 AWG), recommended three-conductor shielded triad cable
  • Maximum Length: 305 meters (1,000 feet)
• Operational Specifications:
  • Temperature Range: -52°C to +177°C (-62°F to +351°F)
  • Pressure Sealing: Differential pressure sealed with Viton O-ring
  • Recommended Gap Setting: 1.0 mm (40 mils)

FAQ

• What makes the 3300 NSv probe better than the previous models?
• The 3300 NSv probe features increased chemical resistance and superior side-view characteristics, enabling more effective measurement and monitoring in harsh environments.
• Can this probe be used in extreme temperatures?
• Yes, the probe operates effectively within a temperature range of -52°C to +177°C, making it suitable for various industrial applications.
• What is the recommended gap setting for the NSv probe?
• The recommended gap setting is 1.0 mm (40 mils), ensuring optimal performance during operation.

For more detailed information: 3300 XL NSv Proximity Transducer System Datasheet
