FECA-01 ABB Ethernet Adapter Module

Overview

The ABB FECA-01 Ethernet Adapter Module is designed for seamless integration into ABB drives, providing robust connectivity for EtherCAT communication. It enables the reliable exchange of data between EtherCAT-compliant devices, ensuring efficient automation control.

Key Features:

• EtherCAT Protocol Support: Fully supports EtherCAT communication for high-performance data transfer.
• Power Supply: Powered by the drive with +3.3V and max. 450 mA.
• Durability: Features IP20 protection rating, ensuring operational reliability in most industrial environments.
• Indicators: Includes two green LEDs (LINK/ACT) and one bicolor LED (STATUS) for easy troubleshooting and status monitoring.
• Modular Design: Connects to the drive via a 20-pin connector (X3), with additional connectivity options using two 8P8C modular jacks (X1 and X2).

Technical Specifications:

• Brand: ABB
• Model: FECA-01
• Protection Degree: IP20
• Compatibility: All EtherCAT-compliant devices
• Connector: 8P8C modular jack (RJ-45)
• Power Supply: +3.3V ±5%, max. 450mA (provided by drive)
• Transfer Rate: 100 Mbit/s (100BASE-TX)
• Wiring: Cat 5e FTP or STP (UTP)
• Maximum Segment Length: 100 m
• Topology: Daisy chain
• Serial Communication Type: Full duplex
• Protocol: EtherCAT
• Compliance: EMC standard EN 61800-3:2004
• PCB Coating: Conformal coated for environmental resilience

FAQ:

Q: What drives is the FECA-01 compatible with?

A: The FECA-01 is compatible with all EtherCAT-compliant ABB drives.

Q: What type of cabling is recommended for the FECA-01?

A: For optimal performance, use Cat 5e FTP or STP cables. UTP cables are also supported.

Q: How can I monitor the FECA-01’s status?

A: The module includes two green LEDs (LINK/ACT) and one bicolor LED (STATUS) to provide feedback on connectivity and operational status.

For more detailed information: EN_FENA_01_EthernetIP_ProtocolManual_A
