GE Fanuc IC693CPU350 Series 90-30 CPU Module

Overview

The GE Fanuc IC693CPU350 is a single-slot Series 90-30 CPU module, designed to enhance industrial control systems. It operates with a 25 MHz processor (80386EX) and offers 32K bytes of user memory with RAM and Flash storage. Ideal for applications in industries like motion control, water treatment, and material handling, it ensures flexibility and scalability with support for various field bus interfaces and communication protocols.

Key Features

• Processor Speed: 25 MHz (80386EX processor)
• User Memory: 32K Bytes (RAM and Flash)
• Scan Rate: 0.22 milliseconds per 1K of logic (Boolean contacts)
• Power Requirements: 670 milliamps from a +5 VDC supply
• Compatibility: GE Fanuc 90-30 PLCs, supports digital and analog modules
• Built-in Communication Ports: RS-485 via power supply (serial port), Ethernet (supports SRTP, Modbus TCP/IP)
• Timers/Counters: More than 2000
• Programming Languages Supported: Ladder Diagram (LDI), Instruction List (IL), Structured Text (ST), C Block
• I/O Points: Up to 2048
• Field Bus Interface Modules: Supports multiple protocols such as Ethernet, FIP, Profibus, GBC, GCM, and more.
• Scalable System: Users can configure the system to their needs with the option to expand later without changing software.

Technical Specifications

• Brand: GE Fanuc
• Model: IC693CPU350
• Processor Type: 80386EX
• Processor Speed: 25 MHz
• Operating Temperature: 0 to 60°C (32 to 140°F)
• Storage Temperature: -40 to 85°C (-40 to 185°F)
• Voltage Input: 5 Volts DC
• Current Input: 670 milliamps
• I/O Points: 2048
• Memory: 32K Bytes (RAM and Flash)
• Timers/Counters: Over 2000
• Scan Rate: 0.22 ms per 1K logic (Boolean contacts)
• Compatibility: GE Fanuc 90-30 PLCs
• Field Bus: Supports Ethernet, Profibus, FIP, GBC, and more
• Communication Protocols: SRTP, Modbus TCP/IP, SNP/SNP-X
