GE Fanuc IC695CRU320 RX3i Redundancy CPU

Overview

The GE Fanuc / Emerson Automation IC695CRU320 is a robust redundancy processor from the PACSystem RX3i series. It features a 1 GHz Celeron M microprocessor, dual RS232/RS485 serial ports, and a switchover time as low as 3.133 ms. With 64 MB battery-backed RAM and 64 MB non-volatile flash memory, it ensures efficient program storage and execution. Ideal for high-availability systems, it supports up to 512 program blocks and operates reliably within a temperature range of 0 to 60°C.

Features and Benefits

1. High-Performance Processor: 1 GHz Celeron M for fast and reliable execution.
2. Redundant Operation: Ensures seamless switchover within one logic scan or 3.133 ms.
3. Ample Memory: Includes 64 MB of battery-backed RAM and 64 MB of NVRAM for program storage.
4. Dual Serial Ports: Supports RS232 and RS485 communication standards.
5. Flexible Power Options: Compatible with IC695ACC302 Lithium Smart Battery and IC693ACC302 auxiliary modules.
6. Broad Compatibility: Designed for PACSystems RX3i automation platforms.

Technical Specifications

• Brand: GE Fanuc / Emerson Automation
• Model: IC695CRU320
• Processor: Celeron M, 1 GHz
• RAM/NVRAM: 64 MB each
• Serial Ports: 2 (RS232/RS485)
• Max Program Blocks: 512
• Switchover Time: Min. 3.133 ms, Max. 1 logic scan
• Power Requirements: 1 A at 3.3 V DC, 1.2 A at 5 V DC
• Maximum Block Size: 128 KB
• Temperature Range: 0°C to 60°C
• Batteries: IC695ACC302, IC693ACC302

FAQ

1. What does the IC695CRU320 processor do in a redundancy setup?
It ensures seamless control switchover to a backup processor within one logic scan or a minimum of 3.133 ms to maintain system uptime.

2. How many serial ports does it have?
It features two serial communication ports supporting RS232 and RS485.

3. What are the power requirements?
It requires 1 A at 3.3 V DC and 1.2 A at 5 V DC.

4. Can the processor handle large program sizes?
Yes, it supports up to 512 program blocks with a maximum block size of 128 KB.

5. What batteries are compatible?
It is compatible with IC695ACC302 Lithium Smart Battery and IC693ACC302 auxiliary battery module.

For more detailed information, please check official datasheet. GFK2514AD_IC695CRU320-EZ_IPI
