GE Fanuc RX3i IC695CPE305 Central Processing Unit

Overview

The IC695CPE305 is an advanced Programmable Automation Controller (PAC) from the PACSystems RX3i series, developed by GE Fanuc, now a part of Emerson Automation. It provides exceptional processing capabilities and communication options suitable for various industrial automation applications.

Technical Specifications

• Brand: GE Fanuc (Emerson Automation)
• Model: IC695CPE305
• Product Type: CPU Module
• Compatibility: PACSystems RX3i
• Clock Speed: 1.1 GHz
• RAM: 5 MB
• Non-volatile Memory: 5 MB User Memory
• Operating Temperature: 0 to 60 degrees Celsius
• Power Requirements:
  • 1 Amp at +5 V DC
  • 1 Amp at +3.3 V DC
  • 0.5 Amps at +24 V DC
• Switchover Time: Maximum 1 logic scan, minimum 3.133 ms
• Serial Ports:
  • 2 Ports (RS232, RS485)
• Ethernet Ports:
  • 1 Port (10/100 Mbps)
• USB Ports:
  • 1 USB 2.0 Master Port
• Maximum Program Blocks: 512
• Maximum Block Size: 128 kilobytes
• Floating Point Capability: Yes
• Protocol Support:
  • Modbus RTU Slave
  • Serial I/O
  • Genius, PROFIBUS DP, DeviceNet, etc.
• Backplane: Universal backplane
• Number of Slots: 1
• Number of Local Racks: Up to 8
• Type of Memory Storage: SRAM, Flash
• Batteries Used:
  • IC695ACC302 Lithium Smart Battery
  • IC693ACC302 Series 90-30 Auxiliary Battery Module
  • IC698ACC701 Smart Coin Cell Battery Pack

FAQ

• What is the significance of the clock speed of the IC695CPE305?
  The 1.1 GHz clock speed ensures efficient processing of automation tasks, leading to faster response times.
• How many local racks can this controller support?
  It supports up to 8 local racks, providing scalability for complex automation systems.
• What types of communication does the IC695CPE305 support?
  This controller supports RS232, RS485, Ethernet, and USB communication protocols for versatile connectivity.
