GE Fanuc | VersaMax PLC CPU IC200CPU001

Overview

The IC200CPU001 is a Central Processing Unit (CPU) from the VersaMax series, designed by Emerson Automation, formerly produced by GE Intelligent Platforms (GE IP). This compact and highly flexible PLC (Programmable Logic Controller) is equipped with 34K Bytes of configurable memory, offering efficient control and data handling. It is ideal for discrete and analog applications, supporting 2048 discrete inputs and 2048 discrete outputs.

The IC200CPU001 is designed to meet the needs of a wide range of industrial applications, from process control to automation systems. It provides fast Boolean logic execution, with a scan rate of 1.8 ms per 1K of logic. It also features built-in communication ports for easy integration, making it a versatile solution for industrial control.

Technical Specifications

• Brand: GE Fanuc (Now Emerson Automation)
• Model: IC200CPU001
• Product Type: CPU Module for PLC Systems
• Configurable Memory: 34K Bytes for user programs, registers, and I/O management
• Discrete Inputs: 2048 points
• Discrete Outputs: 2048 points
• Discrete Internal Bits: 1024 points
• Temporary Bits: 256 points
• Boolean Execution Speed: 1.8 ms / K
• Floating Point Math: Supported
• Real-Time Clock (RTC): 100 ppm accuracy (± 9 seconds/day)
• Communication Ports:
  • One RS232 port
  • One RS485 port
• Supported Serial Protocols: Modbus RTU Slave, SNP Slave, Serial I/O
• Memory Type: System Flash, battery-backed RAM
• Current Consumption:
  • 5V Backplane: 140 mA (with EZ Store attached)
  • 3.3V Backplane: 100 mA
• Size: 2.63″ x 5.04″ (66.8 mm x 128 mm)
• Battery-Backed RTC: Installed

FAQ

Q1: What is the maximum I/O capacity of the IC200CPU001?

• A1: The IC200CPU001 supports up to 2048 discrete inputs and 2048 discrete outputs.

Q2: Does the IC200CPU001 support floating-point operations?

• A2: Yes, the IC200CPU001 supports floating-point math for more advanced calculations.

Q3: What communication protocols are supported?

• A3: The CPU supports Modbus RTU Slave, SNP Slave, and Serial I/O protocols, providing flexibility in communication.

Q4: What are the power requirements for this CPU?

• A4: The IC200CPU001 consumes 140 mA at 5V (with EZ Store) and 100 mA at 3.3V.

Q5: Is there a real-time clock in the IC200CPU001?

• A5: Yes, the IC200CPU001 includes a battery-backed Real-Time Clock (RTC) with an accuracy of 100 ppm (± 9 seconds/day).

For more detailed information, please check official datasheet. VersaMax CPU Modules CPU001 and CPU002
