GE Fanuc | VersaMax PLC CPU IC200CPU002

Overview:

The GE Fanuc IC200CPU002 is a versatile CPU module from the Versamax series. It features a user-friendly interface, including a RUN/STOP switch for operation control, and embedded RS-232 and RS-485 communication ports. With a 42 KB memory capacity and support for 2048 digital inputs and 2048 outputs, it is ideal for various industrial automation applications. The module supports programming in ladder diagrams and instruction list languages and includes a built-in real-time clock for accurate timekeeping.

Features:

• Memory Capacity: 42 KB, user-configurable.
• Communication Ports: RS-232 and RS-485 for internal communication.
• Inputs and Outputs: 2048 digital inputs and outputs.
• Power Supply: 5 Volts.
• Run/Stop Switch: Located behind the module door, used for controlling the CPU’s operational state.
• Real-Time Clock: Accuracy of 0.01%, with a time-of-day clock accuracy of 0.0023%.
• LED Indicators: Power, OK, Fault, and status LEDs for operational feedback.
• Mounting: Compatible with horizontal and vertical DIN rail mounting.
• Battery: Powers the real-time clock with a 5-year lifespan.

Technical Specifications:

• Manufacturer: GE Fanuc
• Series: Versamax
• Part Number: IC200CPU002
• Voltage: 5 Volts
• Memory: 42 KB (user-configurable)
• Communication Protocols: RTU slave, SNP slave, Serial I/O
• Switch Options: Run, Stop
• Inputs: 2048 digital inputs
• Outputs: 2048 digital outputs
• Temperature Rating: 30°C
• Battery Life: 5 years for real-time clock.

Applications:

The IC200CPU002 is designed for use in GE PLC systems, offering control and communication capabilities in industrial automation setups. It is suitable for process control, machinery management, and data logging applications, providing seamless integration with other modules and devices in the Versamax series.
