Honeywell ControlNet Repeater Adapter TC-PBFO01

Overview

The TC-PBFO01 is a ControlNet Repeater Adapter designed for hazardous locations, offering reliable communication in environments where safety and performance are critical. This device ensures safe and efficient transmission of data with advanced features, including intrinsic safety and galvanic isolation.

Product Features & Specifications

• Brand: Honeywell
• Model: TC-PBFO01
• ControlNet Compliance: International Version 1.5
• Intrinsically Safe Parameters:
  • Ui ≤ 9.5Vdc
  • Ii ≤ 1A
  • Ci ≤ 120nF
  • Li ≈ 0
• Power Requirements:
  • Power Supply: One unit load
  • Power Dissipation: 8W
  • Power Supply: Intrinsically safe, provides safe operation in hazardous locations
• Communication Rate: 5 Mbps
• Isolation & Safety:
  • Galvanic isolation for TTL, ControlNet, and power supply connections
  • Shock Test: 15g peak for 11ms duration
  • Vibration Test: 2g @ 10Hz to 500Hz (IEC 68-2-6)
• Operating Temperature:
  • Ambient: –20°C to 70°C (–4°F to 158°F)
  • Storage: –20°C to 100°C (–4°F to 212°F)
• Humidity & Pollution:
  • Max. Humidity: 95%, non-condensing
  • Pollution Gas Test: Level G3 (ISA-S71.04-1985)

Physical Dimensions & Specifications

• Dimensions:
  • 92mm x 94mm x 87mm (3.6in x 3.7in x 3.4in)
• Weight: 0.319 kg (0.70 lb)
• Wire Size (Power Terminals): 12 AWG (4mm²) stranded, max. insulation of 1.2mm (0.0469in)
• ControlNet Cable: Belden 3092A (specific to ControlNet standards)

For more detailed information, please check official datasheet: C200-introduction
