Honeywell TC-ODA161 16-Point Discrete Output Module

Key Features:

• Model: TC-ODA161
• Number of Outputs: 16 (4 points/common)
• Output Voltage Range: 74-265 VAC, 47-63 Hz
• Output Current Rating:
  • Per Point: 2 A max at 30°C, 1 A max at 60°C
  • Per Module: 5 A max at 30°C, 4 A max at 60°C
• Surge Current: 20 A for 43 ms, repeatable every 2 seconds at 60°C
• Minimum Load Current: 10 mA per output
• Maximum On-State Voltage Drop:
  • 1.5V peak at 2 A
  • 6V peak at load current <50 mA
• Maximum Off-State Leakage Current: 3 mA per point
• Output Delay Time:
  • Off to On: 1 ms + 1/2 cycle max
  • On to Off: 1 ms + 1/2 cycle max
• Fault States Configuration: Hold Last State, ON or OFF
• Configurable States in Program Mode: Hold Last State, ON or OFF

Power and Isolation:

• Power Dissipation: 6.5 watts
• Backplane Current: Refer to Module Power Consumption Data
• Isolation Voltage:
  • Channel to Channel: 100% tested at 2546 VDC for 1s
  • User to System: 100% tested at 2546 VDC for 1s
• Maximum Inhibit Voltage (Zero Crossing): 60 V peak

Termination and Connection:

• Connection Terminal Blocks: TC-TBNH, 20-position terminal block
• Module Compatibility: Designed for use with TC system components and compatible PLCs

FAQ:

1. What is the maximum surge current rating for TC-ODA161?
   The surge current is rated at 20 A for 43 ms, and it is repeatable every 2 seconds at 60°C.
2. What is the minimum load current per output?
   The minimum load current is 10 mA per output.
3. Can the fault states be configured?
   Yes, the fault states can be configured to Hold Last State, ON, or OFF, providing flexibility in fault management.
4. What is the maximum off-state leakage current?
   The maximum off-state leakage current is 3 mA per point.
5. What type of connection terminal block is required for this module?
   The TC-TBNH, 20-position terminal block is used for wiring this module.

For more detailed information, please check official datasheet: C200-introduction
