Honeywell TC-RPA001 ControlNet Repeater Adapter

Overview:

The TC-RPA001 ControlNet Repeater Adapter is designed for use in non-hazardous locations. It enhances the range and performance of ControlNet communication networks, ensuring reliable data transmission. This device is compliant with ControlNet International Version 1.5 and supports intrinsically safe applications. Its durable design and robust features make it ideal for industrial automation systems requiring high-performance, noise-resistant communication.

Features:

• Fiber Capacity: Supports 2 fiber modules for enhanced network flexibility.
• Input Voltage: 20 to 35Vdc (nominal 24Vdc), with a low ripple of ≤10% for stable operation.
• Power Consumption: 230 to 400mA, ensuring energy efficiency.
• Communication Rate: High-speed 5M bit/s, ensuring fast data transmission.
• Galvanic Isolation: Per DIN EN 50 020 standards for reliable electrical separation.
• ControlNet Compatibility: Complies with ControlNet version 1.5, supporting the most up-to-date industrial communication standards.

Technical Specifications:

• Brand: TC
• Model: TC-RPA001
• Fiber Modules: 2 modules for fiber-optic communication.
• Voltage Rating: 20 to 35Vdc, 24Vdc nominal.
• Power Consumption: 230-400mA, offering energy efficiency for extended use.
• Temperature Range: Operating temperature between –20°C to 70°C, storage temperature from –20°C to 100°C.
• Shock Resistance: 15g peak at 11ms duration to withstand industrial environments.
• Vibration Resistance: 2g at 10Hz to 500Hz as per IEC 68-2-6.

For more detailed information, please check official datasheet: C200-introduction
