IC695ALG106 GE Fanuc RX3i Analog Input Module

Overview

The IC695ALG106 is an advanced analog input module from Emerson Automation, designed for the PACSystem RX3i platform. This module features six isolated input channels, allowing for flexible configuration with a wide range of voltage and current signal types. These include ±10V, 0 to 10V, ±5V, 0 to 5V, 1 to 5V, 0-20 mA, 4-20 mA, and ±20 mA signals. The IC695ALG106 provides precision with a 16-bit analog-to-digital converter (ADC) that offers either Floating Point IEEE 32-bit or 16-bit Integer data formats.

Technical Specifications

• Manufacturer: Emerson Automation (formerly GE Intelligent Platforms)
• Model: PACSystem RX3i
• Part Number: IC695ALG106
• Series: PACSystem RX3i
• Channels: 6 isolated analog input channels
• Signal Types: Voltage (±10V, 0-10V, ±5V, 0-5V, 1-5V) and Current (0-20mA, 4-20mA, ±20mA)
• Resolution: 16 bits
• Power Supply: 24V DC Isolated Voltage
• Current Draw: 230 mA at 5.0V; 320 mA at 3.3V
• Filter Options: 8Hz, 12Hz, 16Hz, 40Hz, 250Hz, 1000Hz
• Calibration: Accuracy of 0.1% at 25°C, 0.2% over full temperature range
• Overcurrent: ±35mA continuous
• Overvoltage: ±35V DC continuous maximum
• Open Circuit Detection: 1 second maximum
• Scan Time: 1ms
• Settling Time: Ranges from 127ms to 0ms, depending on the selected filter
• Temperature Range: Standard operating temperature of 0°C to 60°C

FAQ

• Q1: What software is needed for programming?
  A1: The IC695ALG106 is compatible with Proficy Machine Edition version 5.6 SP11 or later.
• Q2: What is the module’s calibration accuracy?
  A2: The accuracy is 0.1% of range at 25°C and 0.2% over the entire temperature span.
• Q3: How long is the calibration interval?
  A3: The calibration interval is 12 months.
• Q4: What are the overvoltage and overcurrent limits?
  A4: The module supports ±35V DC continuous overvoltage and ±35mA continuous overcurrent.
• Q5: What is the module’s current consumption?
  A5: It draws 230 mA maximum at 5.0V and 320 mA at 3.3V.
