IC695CPE310 GE Fanuc RX3i Central Processing Unit

Overview

The IC695CPE310 is a mid-range Central Processing Unit (CPU) module from the PACSystems RX3i series, manufactured by Emerson Automation, previously known as GE Intelligent Platforms. Known for its robust performance, this controller is designed for various industrial automation applications including discrete manufacturing, automotive, chemical processing, and industrial steam systems.

Technical Specifications

• Brand: GE Fanuc
• Model: IC695CPE310
• Processor Speed: 1.1 GHz
• Boolean Execution Speed: 0.72 ms/k
• User Logic Memory: 10 MB
• Discrete I/O Memory: 32 K
• Analog I/O Memory: 32 K
• Power Requirement:
  • 1 Amp at +5V and +3.3V DC
  • 0.5 Amps at +24V DC
• Communication Ports:
  • One (1) Ethernet port (10/100 Mbps)
  • Two (2) Serial Ports (One RS232 and One RS485)
• Supported Protocols:
  • SNP
  • Modbus Slave and Master
  • Serial I/O
• Local Racks Supported: Up to Eight (8)
• Type of Memory Storage: SRAM, Flash
• Program Storage: 10 MB of User Memory
• Floating Point Processing: Yes
• Backplane: Universal backplane

FAQ

• 1. What is the main advantage of the IC695CPE310?
  The IC695CPE310 offers high processing speed and can handle up to 32K I/O simultaneously, making it ideal for complex applications.
• 2. Can I use this CPU with existing GE equipment?
  Yes, users can easily swap between the CPU310 and CPE310 models without upgrading their legacy PME software.
• 3. Is the IC695CPE310 compatible with advanced programming languages?
  Yes, it supports multiple IEC languages and the C programming language, allowing for versatile application development.
