IC695NIU001 | Ethernet Network Interface Unit

Overview

The IC695NIU001 is a crucial component for connecting PACSystems RX3i and Series 90-30 I/O modules over an Ethernet network. Manufactured by Emerson Automation (formerly known as GE Intelligent Platforms/GE Fanuc), this module enables efficient communication and data exchange in industrial automation applications.

Key Features

• Brand: Emerson Automation
• Model: IC695NIU001
• Type: Ethernet Network Interface Unit (ENIU)
• Product Line: PACSystems RX3i
• Supported Communication Protocols:
  • SNP
  • Modbus RTU Slave
  • Modbus RTU Master
  • Serial I/O
• Communication Ports:
  • Two (2) RS-232 ports
  • One (1) RS-485 port
• Compatibility:
  • Supports Series 90-30 I/O modules.
  • Configurable with RX3i universal backplane.
  • PCI 2.2 standard compliance.
• Memory:
  • Integrated 10 MB flash memory
  • Optional local logic storage of 20 KB
• Power Requirements:
  • +3.3 VDC: 1.25 Amps nominal
  • +5 VDC: 1.0 Amps nominal
  • Internal power at 3.3 VDC: 0.52 A
  • Internal power at 5 VDC: 0.95 A
• Environmental Specifications:
  • Operating Temperature: 0 °C to 60 °C (32 °F to 140 °F)
• Battery Options:
  • RX3i CPU Lithium Smart Battery (catalog number IC695ACC302)
  • Series 90-30 Lithium Battery Pack (IC693ACC302)
  • Smart Coin Cell Battery Pack (IC698ACC701)
• Configuration Software:
  • Machine Edition Logic Developer version 5.51 or later

FAQ

1. What is the purpose of the IC695NIU001?
   • The IC695NIU001 functions as a communication bridge, allowing PACSystems RX3i and Series 90-30 I/O modules to interact over an Ethernet network.
2. What types of protocols does the module support?
   • It supports SNP, Modbus RTU Slave, Modbus RTU Master, and Serial I/O protocols.
3. Which software is needed for configuration?
   • The module can be configured using Machine Edition Logic Developer software version 5.51 or later.
