IC697CPU732 GE Fanuc Series 90-70 CPU Module

GE Fanuc IC697CPU732 Overview

The IC697CPU732 is a central processing unit (CPU) designed for GE Fanuc 90-70 PLCs, offering high performance for controlling industrial equipment and processes in real-time. This single-slot CPU provides seamless communication with I/O modules via a rack-mounted backplane and supports a wide range of configurations. The device is equipped with a 12 MHz 80C186 microprocessor, allowing it to perform floating-point decimal calculations efficiently.

Technical Specifications

• Brand: GE Fanuc
• Model: IC697CPU732
• Series: Series 90-70
• Module Type: Central Processing Unit (CPU)
• Part Number: IC697CPU732
• Current Draw: 1 Amp
• Voltage Input: 5 Volts DC
• Clock Speed: 12 MHz
• Microprocessor: 80C186
• Number of Slots: 1 (Single Slot)
• I/O Points: 512 Inputs and Outputs (any mix)
• Serial Ports: One
• Supports: IC660/IC661 I/O and IC697 I/O modules
• Operating Temperature: 0°C to 60°C
• Application: Ideal for industrial automation, process control, and equipment monitoring.
• DIP Switches: Not required for configuration (no DIP switches or jumpers needed).

Installation Instructions

To install the IC697CPU732:

1. Ensure power is off before making connections.
2. Place the three-position operation switch in the STOP position.
3. Insert the lithium CMOS battery into the battery connection slot.
4. Install the CPU into Slot 1.
5. Power on the device.

For more detailed information, please check official datasheet. GE Fanuc 90-70 IC697CPU732
