Invensys Triconex | 4351B Communication Module

Overview

The Triconex 4351B Tricon Communication Module is a powerful and versatile communication solution designed for industrial control systems. With multiple ports for connectivity and high-speed communication capabilities, it ensures seamless data transfer and real-time monitoring. It supports a wide range of protocols, offering flexibility in integration with various automation systems.

Technical Specifications

• Manufacturer: Triconex
• Model Number: 4351B
• Product Type: Tricon Communication Module
• Ports:
  • Serial Ports: 4 (up to 115.2 Kbps per port)
  • Copper Ethernet Ports: 2 x 10/100 Mbps (Model 4353 supports only 100 Mbps)
  • Fiber Ethernet Ports: 2 x 100 Mbps (MT-RJ connectors)
  • Port Isolation: 500 VDC
• Supported Protocols: TriStation, Modbus, TCP/IP, ICMP, SNTP, TSAA, Trimble GPS, Embedded OPC Server (Models 4353 and 4354), Peer-to-Peer (UDP/IP), Peer-to-Peer Time Synchronization, JetDirect (network printing)
• Communication Speed:
  • Copper Ethernet Ports: 10/100 Mbps
  • Fiber Ethernet Ports: 100 Mbps
  • Serial Ports: Up to 115.2 Kbps per port
• Weight: 3.18 kg
• Status Indicators: PASS, FAULT, ACTIVE, FIRM, LINK, TX (Transmit), RX (Receive)

FAQ

1. What is the difference between Triconex 4351B and Triconex 4353?
   • The 4351B supports a mix of copper and fiber Ethernet ports, while the 4353 adds an embedded OPC server for more advanced automation applications.
2. Can the Triconex 4351B module be used for remote monitoring?
   • Yes, with its support for TCP/IP, SNTP, and Modbus, it is ideal for remote monitoring and control over Ethernet.
3. What is the maximum speed of the serial ports on the Triconex 4351B?
   • The serial ports can support communication speeds of up to 115.2 Kbps per port.
4. Is the Triconex 4351B suitable for use in high-voltage environments?
   • Yes, it features 500 VDC port isolation, making it suitable for industrial environments with high-voltage electrical systems.

For more detailed information, please check official datasheet: Tricon Communication Modules
