Product details
Overview
The MTL5541 is a high-performance repeater power supply designed for hazardous and safe-area applications. Engineered to ensure precise signal transmission, it supports HART® communication and operates efficiently under various environmental conditions. Its compact design and reliable performance make it ideal for industries requiring robust intrinsic safety solutions.
Technical Specifications
- Brand/Model: MTL Instruments MTL5541
- Product Type: Repeater Power Supply
- Channels: One channel
- Transmitter Location:
- Zone 0, IIC, T4–6 hazardous area (certification required)
- Div. 1, Group A hazardous location
- Safe-Area Circuit Ripple: Less than 50µA peak-to-peak
- Transfer Accuracy (at 20°C): Better than 15µA
- Temperature Drift: Below 0.8µA per °C
- Response Time: Settles within 10% of the final value in under 50µs
- Communication Protocol: Supports HART® (terminals 1 & 2)
- LED Indicator:
- Green: Power status indication
- Maximum Current Consumption: 51mA at 24V (with 20mA signal)
- Dimensions:
- Length: 1.58 cm
- Width: 10.98 cm
- Height: 12.36 cm
- Weight: 0.11 Kg
Frequently Asked Questions (FAQ)
- What is the primary application of the MTL5541?
- The MTL5541 ensures reliable signal transmission between hazardous areas and control systems in safe areas.
- Can the device operate in explosive environments?
- Yes, it is certified for Zone 0 (IIC, T4–6) and Division 1 (Group A) hazardous locations when suitably certified.
- Is the MTL5541 compatible with HART® devices?
- Yes, it supports HART® communication via terminals 1 and 2.
- How accurate is the signal transfer at standard temperatures?
- The device provides a transfer accuracy of better than 15µA at 20°C.
- What are the key power requirements?
- It consumes 51mA at 24V when operating with a 20mA signal.
Check official datasheet for more detailed information: MTLx541-S
