PowerFlex 40P Allen-Bradley | 22D-B033N104 AC Drive

Overview

The Allen-Bradley 22D-B033N104 PowerFlex 40P Adjustable Frequency Drive is designed to provide reliable and efficient control for industrial applications. Built by Rockwell Automation, this drive operates with a 3-phase AC input voltage of 240V and delivers a power output of 10 horsepower (7.5 kW). The drive features robust protection mechanisms, ensuring safe operations in non-hazardous indoor environments. Its sensorless vector control principle allows for precise speed regulation and torque management, making it ideal for various industrial machines and systems such as conveyors and diverters.

Technical Specifications

• Manufacturer: Rockwell Automation
• Brand: Allen-Bradley
• Part Number: 22D-B033N104
• Product Line: PowerFlex 40P
• Phase: Three-Phase
• Amperage: 33.0 Amps
• Input Power: 240V AC
• Horsepower: 10 HP (7.5 kW)
• Frame Size: C
• Enclosure: Open NEMA Type, IP20 (Panel Mount)
• Filter: No CE Compliant Filter
• Operating Temperature: -10°C to 50°C (14°F to 122°F)
• Storage Temperature: -40°C to 85°C (-40°F to 185°F)
• Altitude: Up to 1000 meters (3300 feet)
• Vibration Resistance: 1G peak, 5 to 2000 Hz
• Shock Resistance: 15G peak, 11 milliseconds
• Protection: Overcurrent, overload, short circuit/ground fault

FAQ

1. What is the input voltage for the 22D-B033N104 drive?
   • The drive operates on a 240V AC, three-phase input.
2. Is the 22D-B033N104 CE compliant?
   • No, this model does not come with a CE compliant filter.
3. Can this drive be used outdoors?
   • The drive should only be used indoors in non-hazardous environments.
4. What is the maximum temperature the drive can operate at?
   • The operational temperature range is between -10°C to 50°C (14°F to 122°F).

Check official datasheet for more detailed information: PowerFlex 40P
