Proximity Probe 330104-00-06-90-12-05 Bently Nevada With Armor

Overview

The Bently Nevada 330104-00-06-90-12-05 3300 XL 8 mm Proximity Probes are precision instruments designed for monitoring and measuring rotational machinery. With advanced features and materials, these probes ensure high performance and reliability in various applications.

Technical Specifications

• Brand: Bently Nevada
• Model: 3300 XL Proximity Probe
• Product No.: 330104-00-06-90-12-05
• Suffix Meaning:
  • 00: Unthreaded Length Option = 0 mm
  • 06: Overall Case Length Option = 60 mm
  • 90: Total Length Option = 9.0 meters (29.5 feet)
  • 12: Connector and Cable-Type Option = Miniature coaxial ClickLoc connector, FluidLoc cable
  • 05: Agency Approval Option = CSA, ATEX, IECEx Approvals
• Material:
  • Probe Tip: Polyphenylene sulfide (PPS)
  • Probe Case: AISI 303 or 304 stainless steel (SST)
• Weight: 0.323 Kg
• Operating Pressure: Probes designed to seal differential pressure with Viton® O-ring; not pressure tested before shipment
• Temperature Range:
  • Standard Probe: -52°C to +177°C (-62°F to +350°F)
  • Extended Temperature Range Probe:
    • Tip: -52°C to +218°C (-62°F to +425°F)
    • Cable & Connector: -51°C to +260°C (-60°F to +500°F)
• Relative Humidity: Less than 3% change in Average Scale Factor (ASF) tested in 93% humidity for up to 56 days (IEC standard 68 2 3)
• Power Supply Requirements: -17.5 Vdc to -26 Vdc with 12 mA maximum consumption; operates with -23 Vdc to -26 Vdc with barriers
• Output Resistance: 50 Ω
• Sensitivity: Less than 2 mV change in output voltage per volt change in input voltage

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
