Proximity Probe Housing Assemblies | 24701-16-10-00-083-03-02

Overview

Made in the U.S.A, 24701-16-10-00-083-03-02 Proximity Probe Housing Assemblies are designed for industrial applications that require accurate monitoring of machine vibration. With a robust stainless-steel construction and versatile fittings options, these assemblies ensure reliable, long-lasting performance.

Key Features:

• Material: 303 stainless steel body with 304 stainless steel sleeve for durability.
• Weight: 1.8 kg (4.1 lb) typical, without fittings.
• Probe Length: 8.3 inches (083).
• Probe Type: 3300 XL 8 mm with connector.
• Cable Length Option: 1.0 metre (39 inches).
• Mounting Option: 3/4-14 NPT thread (02).
• Fitting Kit: Includes a 3/4-14 NPT plug, reducer, and cable seal grips (for cables of sizes 1/8 to 3/16, 1/4 to 5/16, and 5/16 to 3/8 inches).

Technical Specifications:

• Brand: Bently Nevada
• Product No: 24701-16-10-00-083-03-02
• Probe Option: 16 – 3300 XL 8 mm probe
• Material Construction: 303 stainless steel (body), 304 stainless steel (sleeve)
• Probe Cable Length: 1.0 metre (39 in)
• Probe Penetration: 8.3 inches (083)
• Fitting Kit: Includes plug, reducer, and cable grip
• Mounting Thread: 3/4-14 NPT (02) (Must be ordered if no standoff adapter)
• Weight: 1.8 kg (4.1 lb), without fittings
• Optional Features: Standoff adapter, conduit fittings, and probe flag labels.

FAQ:

• Q1: What is the maximum probe penetration length available with this assembly?
  • A1: This assembly supports probe penetration lengths up to 8.3 inches (083).
• Q2: Can I add a standoff adapter to this assembly?
  • A2: Yes, the standoff adapter is optional and can be added if needed.
• Q3: What is the thread size for mounting?
  • A3: The mounting thread option is 3/4-14 NPT, which is required if no standoff adapter is selected.
• Q4: What is included in the fitting kit?
  • A4: The kit includes a 3/4-14 NPT plug, a reducer (3/4-14 to 1/2-14), and cable seal grips for various cable sizes.

Check official datasheet for more detailed information:21000- 24701- and 164818 Proximity Probe Housing Assemblies Datasheet
