Proximity Probes – 330101-00-12-20-02-05 – Bently Nevada

Product Introduction

The Bently Nevada 330101 – 00 – 12 – 20 – 02 – 05 3300 XL 8 mm Probe is a high – end industrial sensing product manufactured in the U.S.A. It comes with the option of obtaining a Certificate of Origin (COO), making it suitable for a wide range of industrial applications. This probe showcases improvements over previous models, incorporating advanced features for enhanced performance and durability.

Technical Specifications for 330101 – 00 – 12 – 20 – 02 – 05

• • Unthreaded Length Option: “00” represents 0.0 in
  • Overall Case Length Option: “12” indicates 1.2 in
  • Total Length Option: “20” stands for 2.0 meters (6.6 feet)
  • Connector and Cable – Type Option: “02” means Miniature coaxial ClickLoc connector, standard cable
• Electrical Characteristics
  • Nominal Probe DC Resistance:
    • For a 2.5 – meter – long probe, RPROBE is 8.20 ± 0.60 Ω
    • For a 3.0 – meter – long probe, RPROBE is 8.55 ± 0.70 Ω
  • Extension Cable Capacitance:
    • For a 1 – meter extension cable, capacitance is 70.5 pF/m (21.5 pF/ft)
    • For a 1.5 – meter extension cable, capacitance is 71.0 pF/m (21.7 pF/ft)
  • Field Wiring:
    • Recommended wire size can also be 0.3 to 1.8 mm² (14 to 22 AWG)
    • Maximum length between the 3300 XL Proximitor Sensor and the monitor can be adjusted to 250 meters (820 feet) for certain applications

Contact Information

For any inquiries regarding this product, please contact [email protected].
