Proximity Probes 330103-00-03-10-01-05 | Bently Nevada

Overview

The BentlyNevada 330103-00-03-10-01-05 represents the gold standard in industrial vibration monitoring technology. As part of the renowned 3300 XL series, this 8mm proximity probe delivers exceptional measurement accuracy for critical machinery protection. Engineered with premium materials and rigorous quality standards, it provides reliable performance even in extreme operating conditions across multiple industries.

Key Features

• Superior Durability: Constructed with AISI 303/304 stainless steel case and PPS probe tip material for maximum resistance to corrosion and wear
• Precision Engineering: Offers a linear measurement range of 2mm (80 mils) with recommended gap setting at -9Vdc (1.27mm/50 mils)
• Extended Temperature Range: Operates reliably from -52°C to +177°C (-62°F to +350°F), with optional high-temp version available

Technical Specifications

• Electrical Characteristics:
  • Nominal DC Resistance: 7.59Ω ±0.50 (1.0m cable)
  • Field Wiring Compatibility: 0.2 to 1.5 mm² (16-24 AWG)
  • Maximum Cable Length: 305m (1000ft) between probe and monitor
• Mechanical Properties:
  • Probe Weight: 323 g/m (11.4 oz)
  • Thread Specifications: M10x1 with Viton® O-ring seal
  • Unthreaded Length: 0mm (00 option)
  • Overall Case Length: 3mm (03 option)

Ordering Information

The model number 330103-00-03-10-01-05 breaks down as:

• 330103: Base part number for 8mm probe
• 00: 0mm unthreaded length
• 03: 3mm overall case length
• 10: 1.0 meter cable length
• 01: Miniature coaxial ClickLoc connector
• 05: CSA, ATEX, IECEx approvals

Contact Information

For any inquiries, please contact: [email protected]
For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
