Reverse Mount Probe 330105-02-12-90-02-CN | Bently Nevada

Overview

The Bently Nevada 3300 XL 8 mm Reverse Mount Probe (Product No. 330105-02-12-90-02-CN) is a high-performance proximity probe, engineered for industrial applications where precision and reliability are crucial. Manufactured in the U.S.A, this model offers outstanding durability and operational accuracy for monitoring machinery vibration and position. It features an advanced design that incorporates robust materials and a unique probe tip molding method, enhancing its resistance to harsh conditions.

Technical Specifications

• Brand: Bently Nevada
• Model: 3300 XL 8 mm Reverse Mount Probe
• Product Number: 330105-02-12-90-02-CN
• Thread Size: 3/8-24 UNF threads
• Total Length: 9.0 meters (29.5 feet)
• Connector Type: Miniature ClickLoc coaxial connector
• Agency Approval: CN (Country Specific)
• Minimum Target Size: 15.2 mm (0.6 in) diameter (flat target)
• Weight: 0.323 kg
• Dimensions: 20.4 cm x 22.2 cm x 3.7 cm
• Probe Tip Material: Polyphenylene sulfide (PPS)
• Probe Case Material: AISI 303 or 304 stainless steel (SST)
• Maximum Thread Engagement: 0.563 in (3/8-24)
• Operating Temperature:
  • Standard Probe: -52°C to +177°C (-62°F to +350°F)
  • Extended Temperature Range Probe:
    • Probe Tip: -52°C to +218°C (-62°F to +425°F)
    • Probe Cable & Connector: -51°C to +260°C (-60°F to +500°F)
• Nominal Probe DC Resistance: 9.87 ± 0.50 ohms (at 9.0 m length)
• Probe Case Torque:
  • Maximum Rated Torque: 22.6 N•m (200 in•lbf)
  • Recommended Torque: 7.5 N•m (66 in•lbf)
• Sealing Material: Viton® O-ring (ensures pressure sealing between probe tip and case)

FAQ

1. What is the maximum rated torque for the probe?
   The maximum rated torque for the 3300 XL 8 mm Reverse Mount Probe is 22.6 N•m (200 in•lbf).
2. What is the purpose of the Viton® O-ring?
   The Viton® O-ring ensures a pressure seal between the probe tip and case, ideal for applications involving differential pressure.
3. Can I request a pressure test for this probe?
   The probe is not pressure tested before shipment, but custom testing can be requested through the design department.
4. What is the recommended probe cable length?
   This model is available with a 9.0-meter (29.5-foot) cable length.
5. Can this probe be used in high-temperature environments?
   Yes, the extended temperature range probe can operate at temperatures up to +425°F for the probe tip and +500°F for the cable and connector.

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
