Reverse Mount Probes | Bently Nevada 330906-02-12-50-02-05

Overview:

The Bently Nevada 3300 NSv Reverse Mount Probe, model number 330906-02-12-50-02-05, is engineered for high-performance vibration monitoring in industrial environments. Manufactured in the USA, this probe is designed for use with Bently Nevada’s Proximitor sensors to provide precise vibration measurement. Its robust construction includes an AISI 304 stainless steel case, ensuring durability in challenging environments, while its polyphenylene sulfide (PPS) probe tip guarantees resistance to wear. With options for varying probe lengths and connector types, it offers excellent versatility for a wide range of applications.

Technical Specifications:

• Brand: Bently Nevada
• Model: 330906-02-12-50-02-05
• Product Type: 3300 NSv Reverse Mount Probe
• Thread Type: 3/8-24 UNF
• Total Length Option: 50 (5.0 meters or 16.4 feet)
• Connector Type: Miniature coaxial ClickLoc (standard cable)
• Agency Approval: Multiple approvals
• Probe Tip Material: Polyphenylene sulfide (PPS)
• Probe Case Material: AISI 304 stainless steel (SST)
• Cable Specifications: 75Ω coaxial, FEP insulated probe cable, available in 0.5, 1, 5, or 7 meters
• Probe DC Resistance (at 5 meters): 5.3 ± 0.7 ohms
• Tensile Strength (maximum): 220 N (50 lb)
• Operating Temperature: -52°C to +177°C (-62°F to +351°F)
• Storage Temperature: -52°C to +177°C (-62°F to +351°F)
• Maximum Thread Engagement: 0.563 inches (3/8-24)
• Weight: 14 to 150 g (0.5 to 5.3 oz)

FAQ:

Q: What is the maximum operating temperature for the 3300 NSv Reverse Mount Probe?
A: The probe can operate in temperatures ranging from -52°C to +177°C (-62°F to +351°F).

Q: What is the function of the ClickLoc connector?
A: The ClickLoc connector locks into place, preventing disconnection and ensuring reliable signal transmission.

For more detailed information: 3300 XL NSv Proximity Transducer System Datasheet
