Reverse Mount Probes | Bently Nevada 330907-05-30-05-12-05

🌐 Overview

The Bently Nevada 3300 NSv Reverse Mount Probe (330907-05-30-05-12-05) is engineered for superior performance in process compressor applications. Compared to the 3300 RAM probe, this model provides enhanced chemical resistance, making it highly reliable in harsh environments. It also offers improved side-view characteristics over the 3000-series 190 probe, ensuring accurate gap measurement. Designed with robust construction and a secure ClickLoc connector, this probe is built for durability and stability.

📌 Ordering Information

• Brand: Bently Nevada
• Model: 330907-05-30-05-12-05
• Thread Type: M10X1
• Total Length Option: 05 → 0.5 meters (20 inches)
• Connector Type: 12 → Miniature coaxial ClickLoc connector with FluidLoc cable
• Agency Approval: 05 → Multiple approvals
• Made in: U.S.A

📊 Technical Specifications

🔧 Electrical

• DC Resistance (RPROBE): 4.0 ± 0.5 ohms (for 0.5m probe length)
• Linear Range: 1.5 mm (60 mils), from 0.25 to 1.75 mm (10 to 70 mils)
• Recommended Gap Setting: 1.0 mm (40 mils)
• Field Wiring: Supports 16 to 24 AWG (0.2 to 1.5 mm²), recommended three-conductor shielded triad cable

⚙️ Mechanical

• Probe Tip Material: Polyphenylene sulfide (PPS)
• Probe Case Material: AISI 304 stainless steel (SST)
• Maximum Probe Case Torque:
  • Reverse mount probes: 22.6 N•m (200 in•lb)
  • Recommended torque: 7.5 N•m (66 in•lb)
• System Weight: 14 to 150 g (0.5 to 5.3 oz)
• Thread Engagement Length: 15 mm (M10x1)

🌡️ Environmental

• Operating Temperature: -52°C to +177°C (-62°F to +351°F)
• Storage Temperature: -52°C to +177°C (-62°F to +351°F)
• Pressure Resistance: Features a Viton O-ring seal for differential pressure sealing

For more detailed information: 3300 XL NSv Proximity Transducer System Datasheet
