TC-FIL081 Honeywell Thermocouple Analog Input

Technical Specifications

• Brand/Model: TC-FIL081
• Inputs: 8 channels
• Supported Thermocouple Types: B, C, E, J, K, N, R, S, T, TXK/XK (L)
• Resolution: 16-bit (2.384 µV typical)
• Accuracy: ±0.025% Full Scale Range (with filter)
• Power Requirements:
  • Voltage: 24V DC nominal (range: 19.2–31.2V DC)
  • Current: 150mA @ 24V DC
  • Power Dissipation: 3W max (10.2 BTU/hr thermal dissipation)
• Dimensions (HxWxD): 1.8mm x 3.7mm x 2.1mm (46in x 94in x 53in)
• Environmental:
  • Operational Temperature: 0 to 55°C (32 to 131°F)
  • Storage Temperature: -40 to 85°C (-40 to 185°F)
  • Relative Humidity: 5–95% non-condensing (operating)
• Safety and Durability:
  • Shock: 30 g (operating), 50 g (non-operating)
  • Vibration: 5 g @ 10–500Hz

FAQ

1. What is the input resolution of the TC-FIL081 module?
The input resolution is 16 bits with a typical value of 2.384 µV.

2. What thermocouple types are supported by this module?
It supports a wide range of thermocouples, including types B, C, E, J, K, N, R, S, T, and TXK/XK (L).

3. How does the module handle open thermocouple detection?
The module provides out-of-range readings with an upscale indication for open thermocouples.

4. Is the TC-FIL081 suitable for high-noise environments?
Yes, with -60 dB normal mode and -115 dB common mode rejection, it is highly resistant to electrical noise.

5. What is the power dissipation of this module?
The module dissipates 3W maximum at 31.2V DC, translating to 10.2 BTU/hr thermal dissipation.

For more detailed information, please check official datasheet: C200-introduction
