Bently Nevada Velomitor CT Velocity Transducer (Model: 190501-12-00-CN)

The Bently Nevada 190501-12-00-CN Velomitor CT Velocity Transducer offers high-precision measurement in critical industrial applications. Built with durability and efficiency in mind, it is an ideal solution for monitoring machinery vibrations, ensuring optimal performance. This model is equipped with a robust 316L stainless steel case, MIL-C-5015 connection interface, and a mounting surface of 33 mm in diameter, designed for reliable operation under harsh conditions.

Key Features & Specifications:

• Model: 190501, Velomitor CT Velocity Transducer
• Mounting Hardware Option: Plate Stud 3/8-in 24 to M8x1
• Connector: 2-pin 316L stainless steel MIL-C5015, top
• Agency Approval: CN (China-specific approvals)
• Mounting Surface: 33 mm (1.3 in) diameter
• Case Material: 316L stainless steel
• Weight: <297 g (10.5 oz), typical
• Height: 82 mm (3.2 in)
• Operating Temperature: -40 °C to +85 °C (-40 °F to +185 °F)
• Storage Temperature: -40 °C to +100 °C (-40 °F to +212 °F)
• Mounting Torque: 4.5 N-m ± 0.6 N-m (40 in-lbf ± 5 in-lbf)
• Sensitivity: 3.94 mV/mm/s (100 mV/in/s) ±5%
• Frequency Response: 3.0 Hz to 900 Hz (180 to 54,000 cpm) ±1.0 dB, 1.5 Hz to 1.0 kHz (90 to 60,000 cpm) ±3.0 dB
• Velocity Range: 63.5 mm/s pk (2.5 in/s pk)
• Temperature Sensitivity: -8% to +5% typical over operating temperature range
• Transverse Response: <5% of axial sensitivity
• Amplitude Linearity: ±2% to 63.5 mm/s pk (2.5 in/s pk)
• Mounted Resonant Frequency: 9 kHz minimum (stud mounted, except quick disconnect)
• Output Bias Voltage: 10.1 Vdc ± 1.0 Vdc, Pin A referenced to Pin B
• Dynamic Output Impedance: <400 Ω typical
• Broadband: 0.229 mm/s (0.009 in/s) pk

FAQs:

1. Can this transducer handle high temperatures?
   Yes, the Velomitor CT is capable of operating in temperatures ranging from -40 °C to +85 °C.
2. How is it mounted?
   The transducer can be mounted using a 3/8-in 24 to M8x1 plate stud, with a mounting torque of 4.5 N-m.

Check official datasheet for more detailed information: 190501 Velomitor CT Transducer Datasheet
