Velomitor Piezo-velocity Sensor 330500-04-00 Bently Nevada

Overview

The Bently Nevada 330500-04-00 Velomitor Piezo-velocity Sensor is an advanced sensor designed for precision measurements. Made in the U.S.A, this sensor is reliable and robust, ensuring accurate velocity measurements.

Features

• Certificate of Origin (COO): Optional
• Mounting Thread Adapter Option: 04 = 1/4 – 20 UNC
• Agency Approval Option: 00 = Not required
• Mounting Torque: 46 kg cm (40 in-lb) max.
• Connector: 2-pin Mil-C-5015 hermetically sealed, 316L stainless steel shell
• Case Material: 316L stainless steel

Technical Specifications

• Manufacturer: Bently Nevada
• Product No.: 330500-04-00
• Brand: Bently Nevada
• Model: Velomitor Piezo-velocity Sensor
• Height: 63.2 mm (2.49 in)
• Diameter: 25.3 mm (0.995 in)
• Weight: 142 grams (5.0 oz), typical
• Polarity: When the sensor case motion is toward the connector, Pin A becomes positive with respect to pin B.
• Sensitivity: 3.94 mV/mm/s (100 mV/in/s) ±5%
• Frequency Response: 4.5 Hz to 5 kHz (270 cpm to 300 kcpm) ±3.0 dB; 6.0 Hz to 2.5 kHz (360 cpm to 150 kcpm) ±0.9 dB
• Temperature Sensitivity: -14% to +7.5% typical over the operating temperature range
• Velocity Range: 1270 mm/s (50 in/s) peak
• Transverse Sensitivity: Less than 5% of sensitivity

FAQ:

Q: What is the frequency range of the 330500-04-00 Velomitor sensor?
A: The sensor has a frequency response of 4.5 Hz to 5 kHz (270 cpm to 300 kcpm) ±3.0 dB and 6.0 Hz to 2.5 kHz (360 cpm to 150 kcpm) ±0.9 dB.

Q: How does the sensor’s polarity work?
A: When the sensor case moves toward the connector, Pin A becomes positive with respect to Pin B.

Q: What is the maximum velocity the sensor can measure?
A: The sensor can measure peak velocities of up to 1270 mm/s (50 in/s).

For more detail information: 330500-Datasheet
