VPM810 ABB 800 Series Turbine Valve Positioner Module

Overview:

The VPM810 is an advanced 800 Series Turbine Valve Positioner Module from ABB, designed to provide precise valve control for turbine applications. It is engineered to integrate seamlessly with ABB’s automation systems, including the Advant AC800M and Advant-800xA platforms. The VPM810 enhances performance with flexible configuration options, robust communication capabilities (such as Profibus), and high compatibility across turbine systems.

Technical Specifications:

• Brand: ABB
• Model: VPM810
• Product Type: I/O Module
• Power Supply: Standard 24VDC
• Weight: 0.204 kg
• Dimensions: Depth 119 mm, Height 106 mm, Width 44 mm
• Environment: WEEE Category 5 (Small Equipment), No batteries required
• Application: Ideal for valve positioner control in turbine systems, such as those used in power generation, oil & gas, and large-scale industrial processes.

FAQ:

Q: What is the maximum current output?
A: The VPM810 has a dual coil servo output with a maximum current of 227mA.

Q: Can the VPM810 interface with other ABB systems?
A: Yes, it features a built-in Profibus interface, which supports open architecture integration and is compatible with other ABB control systems like Advant AC800M.

Q: How is the VPM810 installed?
A: It can be mounted on a DIN rail or directly on the turbine deck for new installations, or it can be retrofitted into existing setups with standard 24VDC power supplies.

For more detailed information, please check official datasheet:Sales Brochure VP800 Rev B
